Cabling the Workstation
FIGURE 1-6 illustrates the cabling connections for the workstation. The cables and
their connections are described in
TABLE 1-2.
Connect the workstation and external devices in this order (
FIGURE 1-6):
1. Connect the workstation power cord to a grounded electrical outlet.
2. Connect the keyboard and mouse to two of the four USB connectors on the
workstation.
3. Connect the monitor power cord to a grounded electrical outlet.
4. Connect the monitor cable to the VGA video connector or to a graphics
accelerator, if installed.
Note – Some monitors will require installation of the Sun 13W3 to VGA adapter
cable (530-2917-01) before the monitor is connected to the workstation.
5. Connect the Ethernet cable to the TPE connector.
6. Connect any additional external devices to the workstation’s other connectors.
Note – If additional cabling instructions are needed, see Setting Up the Sun Blade 150
System (816-1162) poster.
TABLE 1-2 Cabling the Workstation
Item in FIGURE 1-6 Description
1 Power cord connection from 120 VAC to workstation
2a Keyboard connection to USB port
2b Mouse connection to USB port
3 Power cord connection from 120 VAC to monitor
4 Monitor connection to VGA video connector on workstation
5 Twisted-pair Ethernet (TPE) connection to local area network (LAN)
