Chapter 4 Installing Optional Workstation Hardware 41
Removing the Workstation Cover
Remove the workstation cover as follows:
Caution – Do not operate the workstation with the cover removed. Personal injury
and equipment damage can occur.
1. If you have not already done so, disconnect the workstation power cord to ensure
all power is removed from the workstation (
FIGURE 4-3).
2. At the workstation back panel, use a No. 2 Phillips screwdriver to remove the two
screws that secure the cover (
FIGURE 4-3).
3. Move the cover to the end of the workstation chassis and lift the cover off.
FIGURE 4-3 Removing Workstation Cover
Cover
Screw(2)
Workstation power cord
Chassis
Phillips screwdriver
