Sungrow Logger 3000 User Manual

18
The IP address of ETH1 and ETH2 cannot be within the same internet
segment. Communication failure may follow if otherwise. The default IP
address of ETH1 is 192.168.0.100; ETH2 is 192.168.1.100.
ETH1 is used to set the WEB of the Logger3000 by default and the IP
address cannot activate the DHCP function.
6.5 Protection Earthing Connection
The ground cable should be grounded reliably, otherwise,
Lethal electrical shock to the operator if a fault occurs.
The device may be damaged by lightning.
Step 1 Prepare the ground cable (recommended: outdoor copper-core cable
with cross-sectional area of 4mm
2
~6mm
2
or 12AWG~10AWG) and OT
terminal (M4).
Step 2 Crimp the ground terminal as shown in the figure below.
Step 3 According to the sequence below to secure the M4 bolt to the grounding
hole by spanner with the torque of 5±1N·m.
