7
Unique Remote Transmiers
see Figure 20
is programmed to receive a signal from a unique
communicate with a Motor if the Motor has been
Channel 1 (see Figure 20
Appendix C
Figure 20
Each light represents a separate
which operates as a unique Remote
Operang the EasyShade
25
UP and DOWN
25a. Press and release the UP
EasyShade will roll up into the EasyShade Housing
Up stop limit should stop
25b. Press and release the DOWN
EasyShade will unroll from the EasyShade Housing
Down stop limit should
reaches the physical limit of the Cable Guide
Appendix A
26
Figure 2
CAUTION: Do not leave your Motorized EasyShade
extended during windy condions, as the
uncontrolled movement of the extended EasyShade
Solar Screen Fabric Panel could cause damage to the
product and surrounding items. Simply retract the
Motorized EasyShade by pressing the UP Buon
on the Remote Transmier.
CAUTION: Do not permit the hand-held Remote
Transmier to get wet as this can aect its proper
operaon. It is recommended to keep the Remote
Transmier indoors when the EasyShade is not in
use or if rain is expected.
CAUTION: The installaon procedure for the
Motorized EasyShade includes the use of Cable
Guides to stabilize the extended Solar Screen Fabric
Panel during normal use. If your applicaon does
not permit the installaon of the necessary Cable
Guides or you do not plan to install them, you must
use addional care to prevent damage to your
product. While we do not recommend installing the
Motorized EasyShade without the supplied Cable
Guides, some customers may determine that their
applicaon does not have a vercal surface to install
the supplied Cable Guides as instructed.
“Congratulaons, your installaon is complete.”
