22
L. Stitch width adjustment
Adjust the stitch width of the puller.
(1-1m/m,2-2m/m,3-3m/m, 4-4m/m,5-5m/m)
M. Check
Please change the belt or detach the puller body by pulling
it when checking the machine.
K. Adjust the stopper not to interfere with the puller when the
needle is moving up and down.
stoper
The punched mark should be matched to adjust the stitch width exactly. (Refer to the No.5 item)
Caution
To Next Page
