38
6.14.2) Oil Supply
1) Type of Lubricant
No.
Parts AppliedType of Lubricant
S/M oil
1
Arm, Bed, Hook
Silicon oil
2
Silicon oil supply tank
6.14.3) Oil Supply Method
1) Arm
－ Check the remaining oil volume at the oil tank
installed at the arm before supplying oil.
－ Fill up the oil tank through the oil outlet at the
upper arm.
2) Bed
－Move the feed bracket in the “A” direction and
check the remaining oil volume from the oil
window. Supply sufficient oil through the oil
tank outlet.
Please lubricate the sewing machine at the first time of using the machine or when the machine
remains unused for a long time.
Caution
To Next Page
