High Voltage Series | Installer Manual10
Auxiliary Tools and Materials
AID/Material
Auxiliary Tools/Materials
Use
Fastening materials (M4*12 M6*12 screws,
M6*100 expansion screws, M6 nuts)
1. Assemble the battery racks and x them on the wall or con-
nect the two racks.
2. Assemble the battery modules and high-voltage control box-
es, and x them to the racks.
CAUTION
Possible damage to the building due to static overload.
1. The total weight of the battery storage system is 628kgs. Ensure that the installation site has
sucient bearing capacity.
2. When selecting the installation site, consider the transportation route and necessary site
cleanup.
High Voltage Series Battery is a high-voltage lithium-ion battery system. It provides a reliable backup power
supply for supermarkets, banks, schools, farms and small factories to smooth the load curve and achieve
peak load transfer. It can also improve the stability of renewable systems and promote the application of
renewable energy.
It is characterized by high integration, good reliability, long service life, wide working temperature range, etc.
The battery energy storage system is modular. Each battery module boasts a capacity of 5.12 kWh. The
complete system supports 12 battery modules in series, your total energy capacity reaching an impressive
61.44 kWh - perfect for any large scale installations.
DESCRIPTION AND INSTALLATION
Installation Precautions
Product Description
Performance
Battery System Energy (12 battery modules) 61.44 kWh
Charge/Discharge Rate (Max) 1C
Max Charge / Discharge Current 100 A
Module Capacity 100 Ah
Working Voltage 538~691 V
Working Temperature Charge: 0~55 ºC / Discharge: -20~55 ºC
General Specication
Battery cell chemistry Lithium Ferro Phosphate (LifePO4 or LFP)
Dimension (W×D×H mm) 13th oor: 589×590×2240
Weight Total (12 battery modules, 1 rack) 628 Kg
Weight of each battery module / battery rack 44 - 85 Kg
The altitude of the Installation site ≤2000m
Humidity 5%~85% (RH)
Warranty Period 10 years
Case protection grade IP20
Certication CE/IEC62619/UN38.3
Technical Data
