High Voltage Series | Installer Manual3
IMPORTANT INFORMATION
WARNING
This symbol indicates information that if ignored, could result in personal
injury or even death due to incorrect handling.
CAUTION
This symbol indicates information that if ignored, could result in personal
injury or physical damage due to incorrect handling.
DANGER
This symbol indicates that the operation may cause electric shock.
PLEASE NOTE
Indicates information that is considered important, but not hazard-related.
Scope
The installation and operation manual applies to the modular battery energy storage system. Please carefully
read this installation and operation manual to ensure the safe installation, preliminary debugging, and main-
tenance of the High Voltage Series. Installation, preliminary debugging, and maintenance must be carried
out by qualied and authorized personnel. Please keep this installation and operation manual and other
applicable documents near the battery energy storage system, so that all personnel involved in installation
or maintenance can access this installation and operation manual at any time.
This installation and operation manual only applies to countries meeting the certication requirements.
Please observe the applicable local laws, regulations, and standards. Standards and legal provisions of other
countries may be inconsistent with the provisions and specications. In this manual. In this case, please con-
tact our after-sales service personnel, Tel: +852 2884 4318 Fax: +8522884 4816/ Email: www.sunsynk.com /
sales@sunsynk.com
High Voltage Series Battery Set
System energy 61.44 kWh (12 x 5.12kWh HV Battery)
Composition HVB750V/100A*1 [HV-SeriesM5.1*12]
BMS 1
13-way battery rack 1
Connectors and cabling Included
HV-Series Set
Meaning of Symbols
Attention! The risk of chemical burns.
If the battery is damaged or fails, it may lead to electrolyte leakage, which in turn causes the
formation of a small amount of hydrouoric acid, among other eects. Contact with these
liquids can cause chemical burns.
Do not subject the battery module to severe impact.
Do not open, disassemble or mechanically change the battery module.
In case of contact with an electrolyte, wash the aected area with clean water immedi-
ately and seek medical advice promptly.
Symbols on Equipment
The following types of warning, prohibition, and mandatory symbols are also used on the equipment.
