High Voltage Series | Installer Manual2
Table of Contents
IMPORTANT INFORMATION 3
Scope 3
HV-Series Set 3
Meaning of Symbols 3
Symbols on Equipment 3
General Safety Information 5
Disclaimer 5
Proper Use 5
Quality Certicate 6
Requirements for Installation Personnel 6
SAFETY 6
Safety Rules 6
Safety Information 6
TRANSPORT TO THE END CUSTOMERS 7
Provisions on Shipping of Battery Modules 7
Package Storage Positions 9
Battery Module 9
PREPARATION 9
Tools Required 9
Auxiliary Tools and Materials 10
DESCRIPTION AND INSTALLATION 10
Installation Precautions 10
Product Description 10
Technical Data 10
Description of Rack 11
Installation of Rack 13
Description of Battery Module 16
Description of High-Voltage Control Box 16
Description of Battery Module in Rack 17
Battery Module Installation on Rack 19
High Voltage Series Battery Startup Steps 19
External 12V Power Supply of High-Voltage Con-
trol Box 20
DISPLAY 20
Home Screen 20
Basic Parameters 20
Fault Indication 21
System Maintenance 21
Main Screen 22
System Maintenance Menu 22
System information 22
Volt/Temp information 23
Relay status 23
Version information 23
Fault Pages 24
Under Voltage (UV) 24
Over Voltage (OV) 24
Under Temperature (UT) 25
Over Temperature (OT) 25
Over Current (OC) 25
Dierent Voltage (DV) 26
Dierent Temperature (DT) 26
Other Faults (OF) 26
Maintenance Interface 27
HVESS-MONITOR USE INSTRUCTIONS 27
Main Page 27
Function List 28
Function Description 29
CAN Communication Conguration 29
Basic Information 29
Parallel Information 31
History Data 31
History Records 32
History Events 33
HVESS-Monitor Real-Time Data Storage 34
Parameter 35
INTER-CAN Firmware Upgrade 36
Manufacture 37
Cell Types 38
Inverter Information 39
PCS CAN Firmware Upgrade 40
FAULT DESCRIPTION 41
FAULT TYPES SUMMARY IN SCREEN AND
HVESS-MONITOR 43
MAINTENANCE AND UPGRADE 45
High Voltage Series Battery Maintenance 45
USB's Upgrade Step 46
BATTERY MODULE STORAGE 46
DISPOSAL 47
APPENDIX 48
Circuit Diagram for On Grid System with 12V
Supply 48
