High Voltage Series | Installer Manual8
Check whether the delivery is complete.
WARNING
During transportation, the battery storage rack may be damaged when it is installed with the bat-
tery module. The battery storage rack is not designed to be transported with the installed battery
modules. Always transport the battery module and the battery rack separately. Once the battery
module is installed, do not move the battery rack, and do not lift it by a lifting device.
If possible, do not remove the transport packaging before arrival at the installation site. Before
removing the transport protector, check if the transport packaging is damaged, and check the im-
pact indicator on the outer packaging of the battery converter. If the impact indicator is triggered,
the possibility of transport damage cannot be ruled out.
Improper transportation of battery modules may cause injury. The single battery module weighs
44 kg. If it falls or slips, it may cause injury. Only use suitable transport and lifting equipment to
ensure safe transport.
Wear safety shoes to avoid the danger of injury. When transporting the battery rack and battery
module, their parts may be crushed due to their heavy weight. Therefore, all persons involved in
transportation must wear safety shoes with toe caps. Please observe the safety regulations for
transportation at the end customer's site, especially during loading and unloading.
During transportation and installation of unpacked battery storage cabinets, the risk of injury in-
creases, especially on sharp metal panels. Therefore, all personnel involved in transportation and
installation must wear protective gloves.
The maximum weight of a single rack of High Voltage Series Battery can reach 628 kg. We suggest
that at least 2-3 people work together to install the battery rack. The lifting device is helpful for
heavy parts, and the pulley or cart for light parts. Be careful not to damage the case. The number
of battery modules stacked shall not be more than 8.
