ECCO SG05LP1 | User Manual15
Inverter Hanging Plate Installation
Battery Connection
For safe operation and compliance, a separate DC over-current protector or disconnect device is required
between the battery and the inverter. In some applications, switching devices may not be required but
over-current protectors are still required. Refer to the typical amperage in the table below for the required
fuse or circuit breaker size.
Model Wire Size Cable(mm2) Torque Value (max.)
7/8kW 2AWG 35 24.5N.m
