4
INNOVATIVE HEARTH PRODUCTS • DIRECT-VENT GAS FIREPLACES (DRT6300/DRC6300) • INSTALLATION INSTRUCTIONS
INTRODUCTION
The DRT/DRC6300 Series direct-vent, sealed-
combustion gas fireplaces operate on natural
or propane gas. These appliances feature a
remotely controlled electronic intermittent pilot
ignition system (manual adjustment of the gas
valve settings is not possible).
The DRT/DRC6300 Series is a decorative fire-
place and may not be installed and operated as
the primary heat source in a dwelling.
Electrical power (120 VAC line voltage) is rec-
ommended to operate the fireplace; however,
four (4) "AA" batteries can be used for full-time
operation or as a backup in case of a power
outage.
Approved Vent Components
These fireplaces are designed, tested, and
listed for operation and installation with Secure
Vent
®
direct vent system components (8" inner,
11" outer) manufactured by Security Chimneys
International.
These approved vent system components
are labeled for identification. USE ONLY AP-
PROVED VENT COMPONENTS. Do NOT use
any other manufacturer’s vent components
with these appliances.
Codes and Standards
These appliances comply with National Safety
Standards and are tested and listed by PFS
(Report No. F14-106) to Z21.50 (in Canada,
CSA-2.22), and CAN/CGA-2.17-M91 in both
USA and Canada, as vented gas fireplaces.
These appliances are listed by PFS Corpora-
tion for installation in bedrooms and mobile
homes.
Installation must conform to local codes. In
the absence of local codes, installation must
comply with the current National Fuel Gas
Code, ANSI Z223.1 (in Canada, the current
CAN/CGA-B149.1 installation code).
The appliance, when installed, must be electri-
cally grounded in accordance with local codes
or, in the absence of local codes, with the
National Electrical Code, ANSI/NFPA 70 (latest
edition) or the Canadian Electrical Code, CSA
C22.1 (latest edition).
TABLE OF CONTENTS
Packaging ......................... 4
Introduction ........................ 4
General Information .................. 5
Massachusetts Requirements .......... 6
Cold Climate Insulation ............... 7
Manufactured Home Requirements ...... 7
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Vent Termination Clearances ........... 8
Minimum Clearances to Combustibles ..... 11
Detailed Installation Steps ............. 11
Typical Installation Sequence .......... 11
Step 1. Framing .................... 11
Fireplace and Framing Specifications ...... 12
Step 2. Routing Gas Line ............. 13
Proper Sizing of Gas Line .............. 13
Step 3. Install the Vent System ........ 14
Vertical Termination Systems ........... 15
Vent Section Length Chart ............. 15
Vertical Vent Tables and Figures ......... 18
Horizontal Termination System ......... 19
Horizontal Vent Tables and Figures ...... 21
Step 4. Field Wiring ................. 23
Step 5. Removing Glass Door
Frame Assembly .................. 25
Step 6. Connecting Gas Line .......... 25
Step 7. Checking Appliance
Operation ........................ 25
Step 8. Installing Logs and Panels ...... 26
Step 9. Installing Glass Door .......... 28
Step 10. Burner Adjustments ........... 28
Finishing Requirements ............... 30
Step 11. Attaching Safety-in-
Operation Warnings ................ 31
Installation Accessories ............... 32
Gas Conversion Kits .................. 33
Operation And Care Of Your Appliance .... 34
Maintenance ........................ 34
Front Glass Enclosure Panel, Removal, and
Installation ......................... 41
Log, Volcanic Stone, and Glowing Ember
Placemen .......................... 42
Burner Adjustments ..................44
Flame Appearance and Sooting ......... 44
Burner Air Shutter Adjustment .......... 45
Electronic Appliance Checkout ......... 45
Ordering Replacement Parts ............ 46
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Lighting Instructions ................. 49
Maintenance Schedule ................ 51
Troubleshooting Guide ................ 52
Replacement Parts List ............... 53
Warranty .......................... 55
Please read and understand these
instructions before beginning your
installation.
PACKAGING
The assembled fireplace is packaged with the
following:
• Literature Kit (plastic bag shipped inside
firebox), containing Installation Instruc-
tions and Care and Operation Manual (this
manual), Safety-in-Operation Warning
Labels, and Warranty.
• One (1) bag Glowing Embers
• One (1) bag Platinum Embers
• One (1) bag Volcanic Stone
• Remote Control and Wall Receiver
Switch Kit
• Door Modesty Shield
• Barrier
• Log Grate
NOTE: For use with fireplace as shipped from fac-
tory only. Not for use with Contemporary Burner/
Floor Kit.
REQUIRED ACCESSORIES
One of the following Firebox Liner Kits:
a. Ceramic Firebox Liner Kit–
Buff Rustic
b. Ceramic Firebox Liner Kit–
Red Rustic
c. Porcelain Firebox Liner Kit–
Black
d. Ceramic Firebox Liner Kit–
Red Herringbone
e. Ceramic Firebox Liner Kit–
Buff Herringbone
NOTE: Porcelain kits include side and
back panels. Optional for use with log sets. Required
when using the contemporary burner/floor kit.
NOTE:
• IF THE BARRIER BECOMES DAMAGED, THE
BARRIER SHALL BE REPLACED WITH THE
MANUFACTURER’S BARRIER FOR THIS
APPLIANCE.
• FOR USE WITH BARRIER(S) PART NO(S).
J7422 (40” MODELS) AND J7423 (45”
MODELS).
