NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
INNOVATIVE HEARTH PRODUCTS • DIRECT-VENT GAS FIREPLACES (DRT6300/DRC6300) • CARE AND OPERATION INSTRUCTIONS
Annually (Before the onset of the Burning Season)
MAINTENANCE TASK ACCOMPLISHING PERSON PROCEDURE
Inspect/Clean Burner, Logs,
and Controls
Qualified Service Technician Inspect valve and ensure it is properly operating. Check piping for
leaks. Vacuum the control compartment, fireplace logs, and burner
area.
Check Flame Patterns and Flame
Height
Qualified Service Technician
Refer to Figure 13 or Figure 14 on Page 20.Verify the flame pattern
and height displayed by the appliance conforms to the picture. Flames
must not impinge on the logs. Ensure flames are steady (not lifting or
floating).
Inspect/Clean Pilot and Burner Qualified Service Technician
Refer to Figure 15 on Page 20. Remove any surface build-up on the
pilot and burner assembly. Wipe the pilot nozzles, igniter/flame rod,
and hood. Ensure the pilot flame engulfs the flame sensor as shown.
Check Vent System Qualified Service Technician Inspect the vent system at the top and at the base (within the firebox)
for signs of blockage or obstruction. Look for any signs of dislocation
or deterioration of the vent components.
NOTE: Excessive condensation can cause corrosion of caps, pipe
& fittings (excessive condensation can be caused by long lateral
runs, too many elbows, and/or exterior portions of the system being
exposed to cold weather). Also, inspect the wall straps or plumbers's
tape to ensure they are securely in place.
Appliance Checkout Qualified Service Technician Perform the appropriate appliance checkout procedure detailed in this
manual.
Replace Glowing Embers Homeowner/Qualified Service
Technician
Remove old ember materials (rockwool) and vacuum the ember
placement area. Place new embers per instructions on Page 11.
Periodically (After the Burning Season)
MAINTENANCE TASK ACCOMPLISHING PERSON PROCEDURE
Clean Firebox Interior Homeowner Carefully remove logs, rockwool, and volcanic stone. Vacuum out
interior of the firebox. Clean firebox walls and log grate. Replace logs,
glowing embers (rockwool), and volcanic stone as detailed in this
manual.
Check Flame Patterns and Flame
Height
Homeowner
Refer to Figure 13 and Figure 14 on Page 20. Verify the flame
pattern and height displayed by the appliance conforms to the picture.
Flames must not impinge on the logs.
Check Vent System Homeowner Inspect the vent system at the top and at the base (within the firebox)
for signs of blockage or obstruction. Look for any signs of dislocation
of the vent components (reconnect or replace as necessary).
Clean Front Glass Enclosure Panel Homeowner Clean as necessary following the directions provided in this manual.
Do not touch or attempt to clean glass while hot.
MAINTENANCE SCHEDULE
Turn off gas and electrical power to the fireplace and allow it to cool before cleaning or servicing the appliance.
