Andiron Grate Kits
The andiron kits attach to the grate assembly.
Classic
Mission
Andiron Grate Kits
Fits
Fireplace
Models
Cat. No. (Model)
Mission Classic
40" & 45"
Models
H2227
(AKM-LSM)
H2228
(AKC-LSM)
Barrier Kits
A Barrier is installed by the manufacturer and required
to be installed during operation of the fireplace. If the
Barrier becomes damaged, discontinue operation
of the fireplace until the Barrier is replaced with the
approved Barrier listed below.
Dual Arch Screen Kits
These Dual Arch screen kits can be placed in front
of the glass enclosure panel to help prevent direct
human contact with the hot glass surface.
Dual Arch Screen Kits
Cat. No. Model Description
H5051 DASK-LSM40-2 Dual Arch
Screen
H5054 DASK-LSM45-2 Dual Arch
Screen
Classic Screen Kits
These Classic Screen kits can be placed in front of the
glass enclosure panel to help prevent direct human
contact with the hot glass surface.
Arch Screen Kits
These Arch Screen kits can be placed in front of the
glass enclosure panel to help prevent direct human
contact with the hot glass surface.
Barrier Kits
Cat. No. Description
J7422 40" Barrier
J7423 45" Barrier
Arch Screen Kits
Cat.
No.
Model Description
H5053 ASK-LSM40-2 Arch Screen Kit
H5056 ASK-LSM45-2 Arch Screen Kit
Classic Screen Kits
Cat. No. Model Description
H5052 SK-LSM40-2 Classic Screen Kit
H5055 SK-LSM45-2 Classic Screen Kit
