Supermicro 5018D-FN4T User Manual

5-4
SUPERSERVER 5018D-FN4T User's Manual
5-4 Memory Support
The X10SDV-TLN4F motherboard supports up to 128GB of DDR4 ECC RDIMM or
64GB of DDR4 ECC/Non-ECC UDIMM with speeds up to 2133MHz in four memory
slots. Populating these DIMM slots with memory modules of the same type and
same size will result in interleaved memory, which improves memory performance.
Check the Supermicro website for recommended memory modules.
CAUTION
Exercise extreme care when installing or removing DIMM modules to
prevent damage.
Memory Population Guidelines
Follow the table below when populating the memory DIMMs.
Recommended Population (Balanced)
DIMMA1 Slot DIMMB1 Slot DIMMA2 Slot DIMMB2 Slot Total System
Memory
4GB 4GB 8GB
4GB 4GB 4GB 4GB 16GB
8GB 8GB 16GB
8GB 8GB 8GB 8GB 32GB
16GB 16GB 16GB 16GB 64GB
CPU
DIMMA1
DIMMA2
DIMMB1
DIMMB2
Figure 5-2. Memory Slot Labels
