Chapter 5: Advanced Motherboard Setup
5-7
X10SDV-TLN4F Motherboard Quick Reference
Headers/Connectors
Connector Description
BT1 Onboard Battery
COM1 COM1 Header
FAN1 ~ FAN3 CPU/System Cooling Fans
IPMI LAN Dedicated IPMI LAN Port
I-SATA0 ~ I-SATA5 Intel Serial ATA Ports (I-SATA0 supports SuperDOM)
I-SGPIO1, I-SGPIO2 Serial Link General Purpose I/O Headers
JGPIO1 General Purpose I/O Expander Header
J6 4-pin Power Connector for HDD use (To provide power from the
motherboard to onboard HDD devices.)
J21 M.2 Slot
JD1 Speaker (Pins 1-3: Power LED, Pins 4-7: Speaker)
JF1 Front Panel Control Header
JIPMB1 4-pin External SMbus I
2
C Header (for an IPMI Card)
JL1 Chassis Intrusion Header
JNVI2C1 NVMe I2C Header
JOH1 Overheat LED Header
JSD1 SATA DOM (Device_On_Module) Power Connector
JSMB1 SMBus Header
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module (TPM)/Port 80 Connector
JUIDB1 Unit Identier (UID) Button
LAN1~LAN2
LAN3~LAN4
Gigabit Ethernet (RJ45) Ports
10G Ethernet (RJ45) Ports (TLN4F Only)
PJ1 4-pin 12V DC Power Connector (To provide alternative power for
special enclosure when the 24-pin ATX power is not in use.)
SLOT7 PCI-E 3.0 x16 Slot
SRW1, SRW2 M.2 Holding Screws
USB 0/1 Back panel USB 3.0 Ports
USB 2/3 Back panel USB 2.0 Ports
USB 4/5 Front Access USB 2.0 Ports
VGA1 Back panel VGA Port
