5-8
SUPERSERVER 5018D-FN4T User's Manual
Jumpers
Jumper Description Default
JBR1 BIOS Recovery Pins 1-2 (Normal)
JBT1 CMOS Clear Open: Normal, Short: Clear CMOS
JI
2
C1/JI
2
C2 SMB to PCI-Exp. Slots Pins 2-3 (Disabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1 LAN1/LAN2 Enable Pins 1-2 (Enabled)
JPME1 ME Recovery Pins 1-2 (Normal)
JPME2 Manufacturing Mode Pins 1-2 (Normal)
JPTG1 10Gb Ethernet Enable Pins 1-2 (Enabled)
JPUSB1 USB Wakeup Pins 1-2 (Enabled) (For USB0/1 Only)
JWD1 Watch Dog Enable Pins 1-2 (Reset)
LED Indicators
LED Description Color/State Status
LEDM1 BMC Heartbeat LED Green: Blinking BMC: Normal
LED3 Power LED Green: On System Power On
LED7 UID Switch LED Blue: On Unit Identied
LED8 Overheat/PWR Fail/Fan
Fail LED
Red: Solid on/
Blinking
Solid On: Overheat,
Blinking: PWR Fail or Fan Fail
