SUPERSERVER 5018D-FN4T User's Manual
5-9 Onboard Indicators
GbE LAN LEDs
There are seven GbE LAN ports on the
motherboard. Each Gigabit Ethernet LAN
port has two LEDs. The Yellow LED in-
dicates connection and activity. The Link
LED may be green, amber or off to indi-
cate the speed of the connection. See the
tables on the right for more information.
Activity LED
Link Speed LED
Color Denition
Off No Connection or 10 Mbps
Amber 1 Gbps
Green 100 Mbps
Link Speed LED
Activity LED
Color Status Denition
Off No Connections
Yellow Flashing Active
Link Speed LED
Activity LED
LAN1 - LAN4
LAN5
BMC Heartbeat LED Status
Color/State Denition
Green: Blinking BMC: Normal
BMC Heartbeat LED (LED2)
A BMC Heartbeat LED is located at
LEDM1. See the table on the right for
more information.
Overheat/PWR Fail/Fan Fail LED
An onboard Overheat/PWR Fail/ Fan Fail
LED is located at LED8. See the table on
the right for more information.
Overheat/PWR Fail/Fan Fail
LED Settings
Color/State Denition
Solid Overheat
Blinking PWR Fail or Fan Fail
Onboard Power LED
An Onboard Power LED is located at
LED3 on the motherboard. When this LED
is on, the system is on. See the table on
the right for more information.
Onboard PWR LED Indicator
LED Settings
LED Color Denition
Off System Off (PWR cable
not connected)
Green System On
