Chapter 5: Advanced Motherboard Setup
5-19
USB Wake-Up
Use the JPUSB1 jumper to enable the
function of "System Waking-Up via USB
devices" for USB0/1. This jumper allows
you to "wake-up" the system by pressing
a key on the USB keyboard or by click-
ing the USB mouse of your system. The
JPUSB1 jumper is used together with
the USB Wake-Up function in the BIOS.
Enable both the jumper and the BIOS
setting to enable this function. See the
table on the right for jumper settings and
connections.
USB Wake-up
Jumper Settings
Pin# Denition
1-2 Enabled (Default)
2-3 Disabled
To Next Page
