SuperServer 1019C-HTN2 User's Manual
Front Chassis Features
Item Feature Description
1 Control Panel Front control panel with LEDs and buttons (see preceding page).
2 Cooling Vent Vent for cool air intake.
3 Rack Ear Brackets Attaches server chassis to the rack.
Figure 1-2. Chassis Front View
Front Features
The SC510FT-203B is a 11.3"-depth mini 1U chassis. See the illustration below for the
features included on the front of the chassis.
1
2
3
3
