34
Chapter 4: Motherboard Connections
4.2 Headers and Connectors
4-pin 12V Power for GPU
JPWR1 is a 4-pin 12V power connector for a GPU card that requires an extra 12V of power,
up to 75W.
Extended CMOS Battery
J18 is a 2-pin connector for an external CMOS battery. Refer to Chapter 3 for battery
installation instructions. This connector is also used to clear the CMOS. The clear the CMOS,
remove the battery, shorts pins 1-2 for more than 10 seconds and then install the battery.
TPM Header
The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80, which is
available from a third-party vendor. A TPM/Port 80 connector is a security device that supports
encryption and authentication in hard drives. It allows the motherboard to deny access if the
TPM associated with the hard drive is not installed in the system.
Trusted Platform Module Header
PinDenitions
Pin# Denition Pin# Denition
1 LCLK 2 GND1
3 LFRAME# 4 No Pin
5 LRESET# 6 +5V/NC
7 LAD3 8 LAD2
9 +3.3V 10 LAD1
11 LAD0 12 GND2
13 SMB_CLK 14 SMB_DAT
15 +3.3V_DUAL 16 SERIRQ
17 GND3 18 CLKRUN#/NC
19 LPCPD# 20 LDRQ# (X)
