Chapter 2: Server Installation
19
Figure 2-1. Installing the System into a Rack
2.3 Installing the System into a Rack
The following is a basic guideline for installing the system into a rack with the rack mounting
hardware provided. You should also refer to the installation instructions that came with the
1.
chassis into a rack.
2. Align the thru-holes of the chassis with the thru-holes of the rack.
3. Insert the mounting screws into the thru-holes in the front of the chassis and through the
thru-holes in the rack
Warning: do not pick up the server with the front handles. They are designed to pull
the system from a rack only.
Warning: Stability hazard. The rack stabilizing mechanism must be in place, or the
stabilize the rack can cause the rack to tip over.
Note:
