SuperServer 1019C-HTN2 User's Manual
24
Installing the CPU Heatsink
Notes:
• 
• Do not apply any thermal grease to the heatsink or the CPU die; the required amount has
already been applied.
1. Place the heatsink on top of the CPU so that the four mounting holes are aligned with
those on the heatsink retention bracket.
2. 
Do not fully tighten the screws or you may damage the CPU.
3. 
screws (be careful not to overtighten).
Figure 3-2. Installing the Heatsink
Mounting Holes
Screw#1
Heatsink Bracket
Screw#2
Motherboard
