SuperServer 1019C-HTN2 User's Manual
26
Memory Support
The X11SCZ-F motherboard supports up to 64GB of DDR4 ECC/Non-ECC UDIMM with
speeds of up to 2666MHz in four slots.
3.4 Memory Support and Installation
DIMMModulePopulationConguration
For optimal memory performance, follow the table below when populating memory.
Recommended Population (Balanced)
DIMMA1 DIMMB1 DIMMA2 DIMMB2 Total System Memory
4GB 4GB 8GB
4GB 4GB 4GB 4GB 16GB
8GB 8GB 16GB
8GB 8GB 8GB 8GB 32GB
16GB 16GB 32GB
16GB 16GB 16GB 16GB 64GB
DIMMB2 (Blue Slot)
DIMMA2 (Blue Slot)
Towards the edge of the motherboard
Towards the CPU
DIMMA1
DIMMB1
DIMM Module Population Sequence
Insert the desired number of DIMMs into the memory slots, starting with DIMMA2, DIMMB2,
then DIMMA1, DIMMB1. Populating these DIMM slots with a pair of memory modules of the
same type and size will result in interleaved memory, which will improve memory performance.
BIOS LICENSE
BAR CODE
BAR CODE
BAR CODE
BAR CODE
BAR CODE
DESIGNED IN USA
X11SCZ-Q
REV:1.10
CPU
2
1
21
C2
17
1
9
C4
C2
C5A
C1
24
16
8
C5A
A1
A2
A9 A10
B10 B9 B2
A11
B11
B12
B13
A12
A13
B12B1 B11B2
A1
A12
B12
B1
B11
B2
A1
A12
18 19
23
22
21 20
JPW1
2423
22
2
3 1 4
JGP1
I-SATA0
I-SATA1
I-SATA2
I-SATA3
I-SATA4
I-SGPIO1
JPV1
JIPMB1
4
3
2
1
JPWR1
JPH1
JD1
JSMB1
FAN3
FAN1
FAN2
FAN4
FANB
FANA
JPT1
JPL2
JPL1
JPME2
JWD1
JSD1
JL1
SP1
AC
BT1
BMC_HB_LED1
A
C
LED1
C
SRW6
SRW5
4
95 1
JTPM1
JPAC1
JBT1
JF1
PCH
J18
DIMMA1
DIMMA2
DIMMB1
DIMMB2
JSD1:SATA DOM POWER
COM1/2
COM3/4
M.2:PCI-E 3.0x4
SUPERDOM
Always populate DIMMx1 first
JSMB1:SMBus1
JD1:
1-4:SPAKER
3-4:BUZZER
2-3:ME MANUFACTURING MODE
1-2:NORMAL
JPME2
JWD1:WATCHDOG
2-3:NMI
1-2:RST(Default)
JPG1:BMC VGA DISABLE JUMPER
1-2:NORMAL (DEFAULT)
2-3:DISABLE BMC VGA
JPAC1
1-2:Enable Audio(DEFAULT)
2-3:DISABLE Audio
JL1:CHASSIS INTRUSION
JPT1 TPM Enable/Disable
1-2:ENABLE
2-3:DISABLE
1-2:Enable
2-3:Disable2-3:Disable
1-2:Enable
JPL2:LAN2
JPL1:LAN1
CPU FAN
USB0
USB7/8 (3.0)
USB1/2
USB3/4
USB5/6
JMD1
2280
22110
USB13/14 (3.1)
LAN1/2
DVI-I/VGA
DP++ 1/2
AUDIO
AUDIO FP
PCH SLOT7 PCI-E 3.0x4(INx8)
CPU SLOT6 PCI-E 3.0x16
PCH SLOT4 PCI-E 3.0x4(INx8)
USB9/10 (3.1)
IPMI_LAN
USB11/12 (3.1)
UID SW
UID LED1
BMC
NMI
PWR
LED
X
HDD
LED
NIC1NIC2
OH
FF
X
RST
PWR
ON
JPG1
1
JRF1
1
JPI2C1
2-3:PEG 2x8
1-2:PEG 1x16
JRF1:
