Chapter 1: Introduction
Table continued on next page.
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JPAC1 Audio Enable/Disable Pins 1-2 (Enable)
JPG1 BMC Video Enable/Disable Pins 1-2 (Enable)
JPL1/JPL2 LAN1/LAN2 Enable/Disable Pins 1-2 (Enable)
JPME2 Manufacturing Mode Pins 1-2 (Normal)
JPT1 Onboard TPM2.0 Enable/Disable Pins 1-2 (Enable)
JRF1
PCI-E Slot 6
x16/x8x8 Bifurcation
Pins 1-2 (x16 lane)
JWD1 Watch Dog Timer Pins 1-2 (Reset)
Connector Description
AUDIO
AUDIO FP Front Panel Audio Header
BT1 Onboard Battery
COM1/2, COM3/4 RS-232 Serial COM Headers
DP++1/2 DisplayPorts
DVI-I Digital Visual Interface Port (Digital and Analog)
FAN1 - FAN4, FANA, FANB Fan Headers (FAN1: CPU Fan)
IPMI LAN Dedicated IPMI LAN Port
I-SATA0 - I-SATA4 Intel® PCH SATA 3.0 Ports (I-SATA0: SuperDOM)
I-SGPIO1 Serial Link General Purpose I/O Header
J18 Extended CMOS Battery Connector
JD1 Speaker/Buzzer (Pins 1-4: Speaker, Pins 3-4: Buzzer)
JF1 Front Control Panel Header
JGP1 General Purpose I/O Header
JIPMB1 System Management Bus Header for an IPMI card
JL1 Chassis Intrusion Header
JMD1 M.2 M-Key PCI-E 3.0 x4/SATA 3 Connector
JPI2C1 Power Supply SMBus I2C Header
JPH1 4-pin Power Connector for HDD
JPV1
8-pin CPU Power Connector for ATX Power (Required) or single 12V DC power for a
special enclosure when 24-pin ATX power is not in use
JPW1 24-pin ATX Power Connector
JPWR1 4-pin 12V Power Connector for GPU card requiring extra 12V power up to 75W
