14
SuperServer 1019C-HTN2 User's Manual
Connector Description
JSD1 SATA Disk On Module (DOM) Power Connector
JSMB1 PCH SMBus Header
JTPM1 Trusted Platform Module (TPM) Header
LAN1/2 Gigabit Ethernet (RJ45) Ports
SLOT4, SLOT7 PCH PCI-E 3.0 x4 Slots (in x8)
SLOT6 CPU PCI-E 3.0 x16 Slot
SP1 Speaker/Buzzer
SRW5 M.2 Holding Screw for 110mm key
SRW6 M.2 Holding Screw for 80mm key
UID SW 
USB0 USB 2.0 Type A Header
USB1/2, USB3/4, USB5/6 Front Accessible USB 2.0 Headers
USB7/8 Front Accessible USB 3.1 Gen 1 Header
USB9/10, USB11/12 Back Panel USB 3.1 Gen 2 Ports
USB13/14 Front Accessible USB 3.1 Gen 2 Header
VGA BMC VGA Port
* USB 3.1 Gen 1 is also referred to as USB 3.0.
LED Description Status
BMC_HB_LED1 BMC Heartbeat LED Blinking Green: BMC normal
LED1 Power LED Solid Green: Power On
UID LED UID LED 
