SuperServer 1019C-HTN2 User's Manual
LAN Ports
There are two 1GbE LAN ports (LAN1/LAN2) on the I/O back panel. The X11SCZ-F also
has a dedicated IPMI LAN port on the I/O back panel. These ports accept RJ45 type cables.

LAN Port
PinDenition
Pin# Denition Pin# Denition
1 TX_D1+ 5 BI_D3-
2 TX_D1- 6 RX_D2-
3 RX_D2+ 7 BI_D4+
4 BI_D3+ 8 BI_D4-
HighDenitionAudioPorts


HD Audio
Color Denition
Green Line Out
Pink Mic In
