Super X11SPi-TF User's Manual
Note: Table is continued on the next page.
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPME2 ME Manufacturing Mode Pins 1-2 (Normal)
JPTG1 LAN Enable/Disable Pins 1-2 (Enabled)
JWD1 Watchdog Timer Pins 1-2 (Reset)
LED Description Status
LE3 M.2 LED Blinking Green: Device Working
LEDBMC BMC Heartbeat LED Blinking Green: BMC Normal
LEDPWR Onboard Power LED Solid Green: Power On
UID-LED Unit Identier (UID) LED Solid Blue: Unit Identied
Connector Description
BT1 Onboard Battery
COM1, COM2 COM Port, COM Header
FAN1 ~ FAN5, FANA, FANB CPU/System Fan Headers
IPMI_LAN Dedicated IPMI LAN Port
I-SATA0 ~ I-SATA7 Intel® PCH SATA 3.0 Ports (with RAID 0, 1, 5, 10)
I-SGPIO1, I-SGPIO2,
S-SGPIO1
Serial Link General Purpose I/O Connection Headers (I-SGPIO: SATA use; S-SGPIO: sSATA
use)
JD1 Speaker/Power LED Indicator (Pins 1-3: Power LED, Pins 4-7: Speaker)
JF1 Front Control Panel Header
JIPMB1 4-pin BMC External I
2
C Header (for an IPMI card)
JL1 Chassis Intrusion Header
JNVI
2
C1 NVMe I
2
C Header
JOH1 Overheat LED Indicator
JPI
2
C1 Power System Management Bus (SMB) I
2
C Header
JPWR1 8-pin Power Connector
JPWR2 24-pin ATX Power Connector
JRK1 Intel RAID Key Header
JSD1, JSD2 SATA DOM Power Connectors
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module/Port 80 Connector
LAN1, LAN2 LAN (RJ45) Ports
M.2 M.2 PCI-E 3.0 x4 Slot (Supports M-Key 2280 and 22110)
MH10, MH11 M.2 Mounting Holes
SLOT1 PCH PCI-E 3.0 x4 (in x8) Slot
