Supermicro X11SPi-TF

33
Chapter 2: Installation
DDR4 Memory Support for 82xx/62xx/52xx/42xx/32xx Platform
DIMM Type
Ranks Per DIMM
and Data Width
DIMM Capacity
(GB)
Speed (MT/s), Voltage (V),
Slot Per Channel (SPC),
and DIMM Per Channel (DPC)
1 Slot Per
Channel
2 Slots Per Channel
DRAM Density 1DPC 1DPC 2DPC
4GB 8GB 1.2V 1.2V 1.2V
RDIMM SRx4 4GB 8GB
2933 2933 2666
RDIMM SRx8 8GB 16GB
RDIMM DRx8 8GB 16GB
RDIMM DRx4 16GB 32GB
RDIMM 3DS
QRx4 N/A 2H-64GB
8Rx4 N/A 4H-128GB
LRDIMM QRx4 32GB 64GB
LRDIMM 3DS
QRx4 N/A 2H-64GB
8Rx4 N/A 4H-128GB
Note: 2933 MHz memory is supported only by the 82xx/62xx series processors.
Memory Population Table for Motherboard based on the
81xx/61xx/51xx/41xx/31xx and 82xx/62xx/52xx/42xx/32xx Platform
Memory Population Table for the X11UP Motherboard w/8 DIMM Slots Onboard
Memory Population Sequence
1 DIMM DIMMA1
2 DIMMs DIMMA1/DIMMD1
3 DIMMs DIMMC1/DIMMB1/DIMMA1
4 DIMMs DIMMB1/DIMMA1/DIMMD1/DIMME1
5 DIMMs
(Unbalanced: not recommended)
DIMMC1/ DIMMB1/DIMMA1/DIMMD1/DIMME1
6 DIMM DIMMC1/DIMMB1/DIMMA1/DIMMD1/DIMME1/DIMMF1
7 DIMMs
(Unbalanced: not recommended)
DIMMC1/DIMMB1/DIMMA1/DIMMA2/DIMMD1/DIMME1/DIMMF1
8 DIMMs DIMMC1/DIMMB1/DIMMA1/DIMMA2/DIMMD2/DIMMD1/DIMME1/DIMMF1
