Super X11SPi-TF User's Manual
1.2 Processor and Chipset Overview
Built upon the functionality and capability of the Intel® Xeon 81xx/61xx/51xx/41xx/31xx series
(Socket P0-LGA3647) processor and the Intel PCH C622 chipset, the X11SPi-TF motherboard
provides system performance, power eciency, and feature sets to address the needs of
next-generation computer users.
With the support of the new Intel Microarchitecture 14nm Process Technology, the X11SPi-TF
dramatically increases system performance for a multitude of server applications.
The Intel PCH C622 chipset provides Enterprise SMbus support, including the following
features:
• DDR4 288-pin memory support
• Support for Management Engine (ME)
• Support of SMBus speeds of up to 400KHz for BMC connectivity
• Improved I/O capabilities to high-storage-capacity congurations
• SPI Enhancements
• Intel Node Manager 3.0 for advanced power monitoring, capping and management for BMC
enhancement (see note below).
• BMC supports remote management, virtualization, and the security package for enterprise
platforms
Note: Note Manager support depends on the power supply used in your system.
1.3 Special Features
Recovery from AC Power Loss
The Basic I/O System (BIOS) provides a setting that determines how the system will respond
when AC power is lost and then restored to the system. You can choose for the system to
remain powered o (in which case you must press the power switch to turn it back on), or
for it to automatically return to the power-on state. See the Advanced BIOS Setup section
for this setting. The default setting is Last State.
