Supermicro X11SPi-TF User Manual

14
Super X11SPi-TF User's Manual
Note: The table above is continued on the next page.
Motherboard Features
CPU
•
Supports an Intel® Xeon 81xx/61xx/51xx/41xx/31xx series (Socket P0-LGA3647) processor with up to 28 cores and a
thermal design power (TDP) of up to 205W
Note: The X11SPi-TF motherboard does not support FPGA or Fabric processors.
Memory
•
Up to 256GB of RDIMM, 512GB of LRDIMM, and 1TB of 3DS LRDIMM DDR4 (288-pin) ECC memory with speeds of up
to 2666MHz in eight memory slots
Note: Memory speed support depends on the processors used in the system.
DIMM Size
• Up to 128GB at 1.2V
Note: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Chipset
•
Intel PCH C622
Expansion Slots
•
One (1) PCI-Express 3.0 x4 Slot (in x8) (PCH SLOT1)
• One (1) PCI-Express 3.0 x8 Slots (CPU SLOT2)
• Two (2) PCI-Express 3.0 x8/x16 Slots (CPU SLOT3, CPU SLOT4: Supports Auto Switch)
• One (1) PCI-Express 3.0 x16 Slot (CPU Slot 6)
• One (1) M.2 PCI-Express 3.0 x4 Slot (Supports M-Key 2280 and 22110)
Network
•
Intel X557 10G PHY
• Intel Ethernet Controller X722 for 10G BASE-T Ports
• One (1) Dedicated IPMI LAN located on the rear I/O panel
Baseboard Management Controller (BMC)
•
ASpeed AST2500 BMC
Graphics
•
Graphics controller via ASpeed AST2500 BMC
Motherboard Features

Supermicro X11SPi-TF Specifications

General

USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of DIMM slots	8
Maximum LRDIMM memory	512 GB
Supported RDIMM module capacity	4GB, 8GB, 16GB, 32GB
Supported DIMM module capacities	4GB, 8GB, 16GB, 32GB, 64GB, 128MB
Supported LRDIMM module capacity	32GB, 64GB
USB 2.0 connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	3
ECC	Yes
Memory voltage	1.2 V
Maximum RDIMM memory	256 GB
Supported memory types	DDR4-SDRAM
Maximum internal memory	1024 GB
Supported memory clock speeds	1600, 1866, 2133, 2400, 2666 MHz
BIOS type	UEFI AMI
ACPI version	6.0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
On-board graphics card model	Aspeed AST2500
Bundled software	Intel® Node Manager, IPMI2.0, KVM w/ dedicated LAN, NMI, SPM, SUM, SuperDoctor® 5, Watchdog
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Processor manufacturer	Intel
Processor thermal power (max)	205 W
Processor number of cores supported	28
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet
Component for	Server
Motherboard form factor	ATX
PCI Express x8 (Gen 2.x) slots	0
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.8 mm
Width	304.8 mm
