Supermicro X11SPi-TF

23
Chapter 2: Installation
Overview of the Processor Carrier Assembly
The processor carrier assembly contains the Intel Xeon Non-Fabric (Non-F) processor and
a processor carrier.
1. Plastic Protective Cover
2. CPU Socket
1. Non-F Processor
2. Processor Carrier
Overview of the CPU Socket
The CPU socket is protected by a plastic protective cover.
