Super X11SPi-TF User's Manual
68
3.3 Frequently Asked Questions
Question: What type of memory does my motherboard support?
Answer: The motherboard supports DDR4 ECC RDIMM, LRDIMM, or 3DS LRDIMM modules.
To enhance memory performance, do not mix memory modules of di󰀨erent speeds and sizes.
Please follow all memory installation instructions given on Section 2-4 in Chapter 2.
Question: How do I update my BIOS under UEFI Shell?
Answer: It is recommended that you do not upgrade your BIOS if you are not experiencing
any problems with your system. Updated BIOS les are located on our website at http://
www.supermicro.com/ResourceApps/BIOS_IPMI_Intel.html. Please check our BIOS warning
message and the information on how to update your BIOS on our website. Select your
motherboard model and download the BIOS le to your computer.Also, check the current
BIOS revision to make sure that it is newer than your BIOS before downloading. To update
your BIOS under the UEFI shell, please unzip the BIOS le onto a USB device formatted
with the FAT/FAT32 le system. When the UEFI shell prompt appears, type fs# to change
the device directory path. Go to the directory that contains the BIOS package you extracted
earlier. Enter ash.nsh BIOSname#.### at the prompt to start the BIOS update process.
Reboot the system when you see the message that the BIOS update has completed. Refer
to Appendix D UEFI BIOS Recovery and/or readme le for more information.
Warning: Do not shut down or reset the system while updating the BIOS to prevent possible
system boot failure!
Note: The SPI BIOS chip used on this motherboard cannot be removed. Send your
motherboard back to our RMA Department at Supermicro for repair. For BIOS Recovery
instructions, please refer to the AMI BIOS Recovery Instructions posted at http://www.
supermicro.com/support/manuals/.

Supermicro X11SPi-TF Specifications

General

USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of DIMM slots	8
Maximum LRDIMM memory	512 GB
Supported RDIMM module capacity	4GB, 8GB, 16GB, 32GB
Supported DIMM module capacities	4GB, 8GB, 16GB, 32GB, 64GB, 128MB
Supported LRDIMM module capacity	32GB, 64GB
USB 2.0 connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	3
ECC	Yes
Memory voltage	1.2 V
Maximum RDIMM memory	256 GB
Supported memory types	DDR4-SDRAM
Maximum internal memory	1024 GB
Supported memory clock speeds	1600, 1866, 2133, 2400, 2666 MHz
BIOS type	UEFI AMI
ACPI version	6.0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
On-board graphics card model	Aspeed AST2500
Bundled software	Intel® Node Manager, IPMI2.0, KVM w/ dedicated LAN, NMI, SPM, SUM, SuperDoctor® 5, Watchdog
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Processor manufacturer	Intel
Processor thermal power (max)	205 W
Processor number of cores supported	28
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet
Component for	Server
Motherboard form factor	ATX
PCI Express x8 (Gen 2.x) slots	0
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.8 mm
Width	304.8 mm
