Supermicro X11SPi-TF User Manual

Chapter 4: BIOS
71
Chapter 4
BIOS
4.1 Introduction
This chapter describes the AMIBIOS™ Setup utility for the motherboard. The BIOS is stored
on a chip and can be easily upgraded using a ash program.
Note: Due to periodic changes to the BIOS, some settings may have been added
or deleted and might not yet be recorded in this manual. Please refer to the Manual
Download area of our website for any changes to the BIOS that may not be reected
in this manual.
Starting the Setup Utility
To enter the BIOS Setup Utility, hit the <Delete> key while the system is booting-up. (In
most cases, the <Delete> key is used to invoke the BIOS setup screen. There are a few
cases when other keys are used, such as <F1>, <F2>, etc.) Each main BIOS menu option
is described in this manual.
The Main BIOS screen has two main frames. The left frame displays all the options that can
be congured. “Grayed-out” options cannot be congured. The right frame displays the key
legend. Above the key legend is an area reserved for a text message. When an option is
selected in the left frame, it is highlighted in white. Often a text message will accompany it.
(Note that the BIOS has default text messages built in. We retain the option to include, omit,
or change any of these text messages.) Settings printed in Bold are the default values.
A "
" indicates a submenu. Highlighting such an item and pressing the <Enter> key will
open the list of settings within that submenu.
The BIOS setup utility uses a key-based navigation system called hot keys. Most of these
hot keys (<F1>, <F2>, <F3>, <Enter>, <ESC>, <Arrow> keys, etc.) can be used at any time
during the setup navigation process.

Supermicro X11SPi-TF Specifications

General

USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of DIMM slots	8
Maximum LRDIMM memory	512 GB
Supported RDIMM module capacity	4GB, 8GB, 16GB, 32GB
Supported DIMM module capacities	4GB, 8GB, 16GB, 32GB, 64GB, 128MB
Supported LRDIMM module capacity	32GB, 64GB
USB 2.0 connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	3
ECC	Yes
Memory voltage	1.2 V
Maximum RDIMM memory	256 GB
Supported memory types	DDR4-SDRAM
Maximum internal memory	1024 GB
Supported memory clock speeds	1600, 1866, 2133, 2400, 2666 MHz
BIOS type	UEFI AMI
ACPI version	6.0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
On-board graphics card model	Aspeed AST2500
Bundled software	Intel® Node Manager, IPMI2.0, KVM w/ dedicated LAN, NMI, SPM, SUM, SuperDoctor® 5, Watchdog
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Processor manufacturer	Intel
Processor thermal power (max)	205 W
Processor number of cores supported	28
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet
Component for	Server
Motherboard form factor	ATX
PCI Express x8 (Gen 2.x) slots	0
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.8 mm
Width	304.8 mm
