Supermicro X11SPi-TF User Manual

3
Preface
Preface
About This Manual
This manual is written for system integrators, IT technicians and knowledgeable end users.
It provides information for the installation and use of the X11SPi-TF motherboard.
About This Motherboard
The Supermicro X11SPi-TF supports an Intel® Xeon 81xx/61xx/51xx/41xx/31xx series
(Socket P0-LGA 3647) processor with up to 28 cores and a thermal design power (TDP) of up
to 205W. Built with the Intel PCH C622 chipset, the X11SPi-TF supports 6-channel, 8-DIMM
DDR4 ECC RDIMM/LRDIMM memory with speeds of up to 2666MHz, SATA 3.0 ports, a M.2
slot, 10G Base-T ports, and a Trusted Platform Module (TPM) header. The X11SPi-TF is
optimized for high-performance, high-end computing platforms that address the needs of next
generation server applications. Please note that this motherboard is intended to be installed
and serviced by professional technicians only. For processor/memory updates, please refer
to our website at http://www.supermicro.com/products/.
Conventions Used in the Manual
Special attention should be given to the following symbols for proper installation and to prevent
damage done to the components or injury to yourself:
Warning! Indicates high voltage may be encountered while performing a procedure.
Warning! Indicates important information given to prevent equipment/property damage
or personal injury.
Important: Important information given to ensure proper system installation or to
relay safety precautions.
Note: Additional Information given to di󰀨erentiate various models or provides infor-
mation for proper system setup.

Supermicro X11SPi-TF Specifications

General

USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of DIMM slots	8
Maximum LRDIMM memory	512 GB
Supported RDIMM module capacity	4GB, 8GB, 16GB, 32GB
Supported DIMM module capacities	4GB, 8GB, 16GB, 32GB, 64GB, 128MB
Supported LRDIMM module capacity	32GB, 64GB
USB 2.0 connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	3
ECC	Yes
Memory voltage	1.2 V
Maximum RDIMM memory	256 GB
Supported memory types	DDR4-SDRAM
Maximum internal memory	1024 GB
Supported memory clock speeds	1600, 1866, 2133, 2400, 2666 MHz
BIOS type	UEFI AMI
ACPI version	6.0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
On-board graphics card model	Aspeed AST2500
Bundled software	Intel® Node Manager, IPMI2.0, KVM w/ dedicated LAN, NMI, SPM, SUM, SuperDoctor® 5, Watchdog
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Processor manufacturer	Intel
Processor thermal power (max)	205 W
Processor number of cores supported	28
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet
Component for	Server
Motherboard form factor	ATX
PCI Express x8 (Gen 2.x) slots	0
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.8 mm
Width	304.8 mm
