1-6
C7H61 User’s Manual
Connectors
# Name Description
1 Backpanel I/O See "Connectors/IO Ports" on page 2-12
2 AUDIO FP Front Panel Audio Header
3 JWOL Legacy Wake-On-LAN Header
4,14 COM2, COM3~8 COM2 Header, COM3~8 (supported on the C7H61 only)
6,7 S/PDIF OUT, S/PDIF IN S/PDIF OUT/IN Digital Audio Headers
9 JL1 Chassis Intrusion Header
11 JWOR Wake-On-Ring Header
15 USB 3.0 1/0 USB Header 1/0 (3.0) (supported on the C7H61 only)
16,45 USB10/11,8/9 USB 2.0 Header 10/11,8/9
17,20 A-SATA 0,1 (ASMedia) SATA 3.0 Ports (up to 6Gb/s)
18 JTPM1 Trusted Platform Module (TPM) Header
19 JSD1 Disk-On-Module (DOM) Power Header
24,22,23,21 I-SATA 0,1,2,3 (Intel) SATA 2.0 Ports
25 B1 System Battery
26,28,37,39 FAN 3,2,1,4 System FAN Headers 3,2,1 (CPU FAN),4
27 U5 BIOS Chip
29,40 JPW1,JPW2 24-Pin, 4-Pin Aux Power Supply Connectors
31 JF1 Front Panel Control Header
33 JLED1 3-Pin Power LED Header
34 Test Header Reserved for OEM
35 JD1 External Speaker Header (Pins 2-3 shorted for internal buzzer)
36 SP1 Internal Buzzer
38 CPU Socket H2 for an LGA 1155 CPU
44 PRINTER LPT1 Header (supported on the C7H61 only)
LED Indicators
# Name Description Color/State Status
30 LED1 Onboard Standby PWR LED Green: Solid on Standby Power is On
