Trusted Platform Module Header
Pin Denitions
Pin # Denition Pin # Denition
1 LCLK 2 GND
3 LFRAME 4 No Pin
5 LRESET 6 VCC5
7 LAD3 8 LAD2
9 VCC3 10 LAD1
11 LAD0 12 GND
13 RSV0 14 RSV1
15 SB3V 16 SERIRQ
17 GND 18 CLKRUN
19 LPCPD 20 RSV2
TPM Header (JTPM1)
This header is used to connect a
Trusted Platform Module (TPM), which
is available from a third-party vendor.
A TPM is a security device that sup-
ports encryption and authentication
in hard drives. It enables the moth-
erboard to deny access if the TPM
associated with the hard drive is not
installed in the system. See the table
on the right for pin denitions.
Front Accessible Audio Header
A 10-pin Audio header is also located
on the motherboard. This header al-
lows you to use the onboard sound
for audio playback. Connect an audio
cable to the audio header to use this
feature. See the tables at right for pin
denitions for these headers.
10-in Audio
Pin Denitions
Pin# Signal Pin#
1 Microphone_Left 6 Ground
2 Audio_Ground 7 Jack_Detect
3 Microphone_Right 8 Key
4 Audio_Detect 9 Line_2_Left
5 Line_2_Right 10 Ground
A. TPM Header
B. Audio Header
