Chapter 1: Introduction
1-7
Notes:
1. CPU Overclocking is supported by this motherboard; however, SMCI does not recommend CPU Overclocking and cannot
resume any responsibility or liability of out_of_spec. overclocking.
2. CATERR_LED is for internal testing only.
Motherboard Features
CPU Single 2nd and 3rd generation Intel
®
Core™ i7/i5/i3,
Pentium, Celeron desktop processor, LGA 1155 socket
Memory Supports up to 16GB of Unbuffered (UDIMM) non-ECC
DDR3 1600/1333/1066 MHz in two memory slots.
Supports dual-channel memory bus
DIMM sizes
UDIMM 1 GB, 2 GB, 4GB, and 8GB
Chipset Intel
®
H61 Express
Expansion Slots One (1) PCI Express 2.0 x1 slot
One (1) PCI Express 2.0/3.0 x16 slot
Five (5) PCI 33 MHz slots
Network Connections Two (2) Gigabit Ethernet Controllers:
LAN1: Intel
®
82579V
LAN2: Intel
®
82574L
Two (2) RJ-45 Rear I/O Panel Connectors with Link and
Activity LEDs
I/O Devices SATA Connections
SATA 3.0 (6Gb/s) Two (2) A-SATA 0~1, via ASMedia
SATA 2.0 (3Gb/s) Four (4) I-SATA 0~3, via Intel
®
H61
USB Devices
Six (6) USB 2.0 ports on the rear I/O panel
All models: Four (4) Front Accessible USB 2.0 ports on
two headers
C7H61 only: Two (2) Front Accessible USB 3.0 ports on
one header
Keyboard/Mouse
One shared PS/2 Keyboard/Mouse port on the I/O
backpanel
Serial (COM) Ports
C7H61: Seven (7) Serial Port headers (COM2~COM8)
C7H61-L: One (1) Serial Port header (COM2)
C7H61: One (1) Serial Port on the back panel (COM1)
Audio
Five (5) Female Mini Jacks for High Denition Audio on
the Back Panel
Front Panel Audio Header
One (1) SP/DIF Optical Out on the back panel
SP/DIF In and SP/DIF Out Headers
