1-8
C7H61 User’s Manual
Super I/O
Nuvoton NCT6776F
BIOS 64 Mb AMI BIOS
®
SPI Flash BIOS
Plug and Play (PnP), PCI 3.0, ACPI 4.0, USB Keyboard
and SMBIOS 2.7
Power Conguration ACPI/ACPM Power Management
Main Switch Override Mechanism
Keyboard Wake-up from Soft-Off
Internal/External Modem Ring-On
Wake-On-LAN (WOL) Header
Power-on mode for AC power recovery
PC Health Monitoring CPU Monitoring
Onboard voltage monitors for Vcore, BAT, 3.3V, 3VSB, 5V,
12V, VTT CPU, VDIMM
CPU 3+1 phase switching voltage regulator
CPU/System overheat LED and control
CPU Thermal Trip support
Intel Adaptive Thermal Monitor support
Fan Control
Fan status monitoring with rmware 4-pin (Pulse Width
Modulation) fan speed control
Low noise fan speed control
System Management PECI (Platform Environment Conguration Interface) 3.0
support
System resource alert via SuperDoctor
®
III
SuperDoctor
®
III, Watch Dog
Chassis Intrusion header and detection
CD Utilities BIOS ash upgrade utility
Drivers and software for Intel
®
H61 Express chipset utili-
ties (available for download)
Other ROHS 6/6 (Full Compliance, Lead Free)
Dimensions ATX form factor (12.0" x 9.6")
