Chapter 4: AMI BIOS
4-5
tors will not capture Interrupt 19, and the drives attached to these adaptors will not
function as bootable devices. The options are Enabled and Disabled.
Power Confi guration
Power Button Function
If this item is set to Instant_Off, the system will power off immediately as soon as
the user presses the power button. If set to 4_Second_Override, the system will
power off when the user presses the power button for 4 seconds or longer. The
options are Instant_Off and 4_Second_Override.
Restore on AC Power Loss
Use this feature to set the power state after a power outage. Select Power-Off for the
system power to remain off after a power outage. Select Power-On for the system
power to be turned on after a power outage. Select Last State to allow the system
to resume its last power state before a power outage. The options are Power-On,
Power-Off and Last State.
VFC
Select Enabled to support VFC (Virtual Forensic Computing), which will allow a user
to rapidly display the screen of a remote computer, or boot a physical, write-blocked
hard drive for computer investigation. The options are Enabled and Disabled.
Processor & Clock Options
Warning: Take Caution when changing the Advanced settings. An incorrect
value, a very high DRAM frequency or incorrect DRAM timing may cause
system to become unstable. When this occurs, revert the item to the default
setting.
This submenu displays the status of the processor used in the motherboard and
allows the user to confi gure the Processor and Clock settings.
Type of the CPU
• : This item displays the CPU type for the motherboard.
Frequency
• : This item displays the CPU frequency for the motherboard.
CPUID
• : This item displays the CPUID for the motherboard.
Microcode Revision
• : This item displays the CPUID for the motherboard.
Cache L1
• : This item displays the size of Cache L1 of the CPU for the moth-
erboard.
