Supermicro C7X99-OCE/C7X99-OCE-F Motherboard User’s Manual
OPEN 1st
OPEN 1st
OPEN 1st
Lever Lock
Lever Lock
Push down and
lock 'Open 1st'
lever
Push down and lock
'Close 1st' lever
.
Gently close
the load plate.
1
2
3
4
7.
Close
the
load
plate
with
the
CPU
inside
the
socke
t.
Lock
the
'Close
1st'
lever
rst,
then
lock
the
'Open
1st'
lever
second.
Use
your thumb to gen
tly push the load levers down to
the lever locks.
35
37
