Chapter 2: Installation
2-5
Socket Keys
CPU Keys
4. Use your thumb and index nger to hold the CPU on its edges.
Align the CPU keys, which are semi-circle cutouts, against the
socket keys.
5. Once they are aligned, carefully lower the CPU straight down into
the socket. (Do not drop the CPU on the socket. Do not move the
CPU horizontally or vertically. Do not rub the CPU against the sur-
face or against any pins of the socket to avoid damaging the CPU
or the socket.)
6. With the CPU inside the socket, inspect the four corners of the CPU
to make sure that the CPU is properly installed.
To Next Page
