Supermicro C7Z270-PG Motherboard User’s Manual
1-3 Motherboard Features
CPU
Single Intel Core i3/i5/i7 7th generation processor in
an LGA1151 type socket.
Memory
Four (4) slots support up to 64GB of unbuffered, non-
ECC, 3600MHz (OC) DDR4 memory
Dual-channel memory
DIMM sizes
Up to 64GB at 1.2V
Chipset
Intel® Z270
Expansion Slots
Four (4) PCI-E 3.0 X16 slots
One (1) PCI-E 3.0 X4 (for Thunderbolt AIC support)
Two (2) M.2 slots
Network
Connections
Two (2) Gigabit Ethernet LAN ports
Intel i219v+ i210
I/O Devices Hard Drive Connections
SATA 3.0 (6Gb/s) Six (6) I-SATA 0~5, via Intel Z270
RAID 0, 1, 5, 10
U.2 Connectors Two (2) U.2 Connectors for 2.5"
SSD Drives
USB Devices
One (1) USB 3.1 Type C (Rear), Three (3) USB 3.1 Type
A (Rear), Four (4) USB 3.0 x4 (2x Rear, 2x Header),
Eight (8) USB 2.0 (2x Rear, 6x Header)
Keyboard/Mouse
One shared PS/2 Keyboard/Mouse port on the I/O
backpanel
Other I/O Ports
One (1) DisplayPort, One (1) HDMI Port
One (1) Serial Port header (COM1)
Audio
One (1) High Denition Audio 7.1 channel connector
supported by Realtek ALC1150 on the back panel
One (1) Front Panel Audio Header
One (1) S/PDIF Out on the rear side of the chassis
Super I/O
Nuvoton NCT6792D-B
