Chapter 1
Introduction
1-1 Overview
The SuperServer 6027TR-HTRF+/H70RF+/H71RF+ is a high-end server comprised
of two main subsystems: the SC827HQ-R1620B 2U server chassis and the
X9DRT-HF+ dual processor serverboard in four hot-swap nodes. Please refer to
our web site for information on operating systems that have been certifi ed for use
with the system (www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have
been included with the SuperServer 6027TR-HTRF+/H70RF+/H71RF+ server, as
listed below:
• Four (4) Plastic air shrouds (MCP-310-82719-0B)
• Heat Sinks
Four (4) 1U passive CPU heat sinks (SNK-P0047PSM)
Four (4) 1U passive CPU heat sinks w/narrow ILM (SNK-P0047PS)
• Four (4) 80x80x38mm cooling fans (FAN-0129L4)
• SATA/SAS Backplane
One (1) SAS Backplane for 12 3.5" HDD (BPN-SAS-827HQ)
Twelve (12) hot-swap 3.5" HDD trays (MCP-220-00075-0B)
6027TR-HTRF+ Only:
Eight (8) 29-cm 30AWG SATA cables (CBL-0483L)
Four (4) 6-port SATA adapter cards (BPN-ADPX9-6SATA-O-P)
6027TR-H70RF+ Only:
Four (4) SAS2 LSI2008 HD adapter cards (BPN-ADP-SAS2-L6I-O-P)
6027TR-H71RF+ Only:
Four (4) SAS2 LSI2108 HD adapter cards (BPN-ADP-SAS2-H6IR-O-P)
• One (1) rails set (MCP-290-00053-0N)
Note: a complete list of safety warnings is provided on the Supermicro web site at
http://www.supermicro.com/about/policies/safety_information.cfm
