1-3
Chapter 1: Introduction
SAS
An LSI
®
SAS2008 or SAS2108 SAS2 controller is integrated into the installed
BPN-ADP-SAS2-L6I-O-P (6027TR-H70RF+) or BPN-ADP-SAS2-H6IR-O-P
(6027TR-H71RF+) adapter cards to provide support for three 6 Gb/s SAS2 (Serial
Attached SCSI) subsystems for each node. The system has RAID 0, 1 and 10 support
(RAID 5 with optional AOC-SAS2-RAID5-KEY) for the SuperServer 6027TR-H70RF+
or RAID 0, 1 and 5 support for the SuperServer 6027TR-H71RF+ server. The SAS
drives are hot-swappable units.
Note: The operating system you use must have RAID support to enable the
hotswap capability and RAID function of the SAS drives.
PCI Expansion Slots
The SuperServer 6027TR-HTRF+/H70RF+/H71RF+ has for each node one (1)
PCI-E 3.0 x8 Slot for SMC-Proprietary Micro LP Card (CPU1 Slot2) and one (1)
PCI-E 3.0 x8 Slot for SMC-Proprietary Daughter (Add-On) Card (CPU1 Slot1).
Onboard Controllers/Ports
The color-coded I/O ports include a VGA (monitor) port, two USB 2.0 ports (an
additional internal USB header and one Type A USB connector are included on the
serverboard), an IPMI 2.0 dedicated LAN port and two Ethernet ports.
Note: For IPMI Confi guration Instructions, please refer to the Embedded BMC
Confi guration User's Guide available @ http://www.supermicro.com/support/
manuals/ for IPMI 2.0 system.
Graphics Controller
The X9DRT-HF+ features an integrated Matrox
®
G200eW Video Controller.
Other Features
Other onboard features that promote system health include onboard voltage
monitors, a chassis intrusion header, auto-switching voltage regulators, chassis and
CPU overheat sensors, virus protection, node manager software and BIOS rescue.
