Supero SUPERSERVER 6027TR-HTRF+ - Control Panel

6-2
SUPERSERVER 6027TR-HTRF+/H70RF+/H71RF+ User's Manual
SAS/SATA Drives (12)
Control Panel
Ethernet Ports
USB Ports
VGA Port
Control Panel
Control Panel
Control Panel
Figure 6-1. Front and Rear Chassis Views
6-2 Control Panel
The control panel is located on the front of the chassis. The LEDs inform you of
system status.
See Chapter 3 for details on the LEDs and the control panel buttons.
