Chapter 5: Advanced Motherboard Setup
5-23
5-11 PCI-Express and Serial ATA Connections
PCI-Express 3.0 x8 Micro LP Card Slot
One PCI-E 3.0 x8 Slot for SMC-Proprietary Micro LP Card (CPU1 Slot2) is located
on the motherboard. Refer to the layout on page 5-14 for the location.
PCI-Express 3.0 x8 Daughter Card Slot
One PCI-E 3.0 x8 Slot for SMC-Proprietary Daughter (Add-On) Card (CPU1 Slot1)
supports a SMC-proprietary daughter card. Refer to the layout on page 5-14 for
the location.
Serial ATA (SATA) Connections
Two SATA ports are located on the
motherboard to provide onboard SATA
support.
SATA Port
Pin Defi nitions
(I-SATA0~I-SATA1)
Pin # Defi nition
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
