SUPERSERVER 6027TR-HTRF+/H70RF+/H71RF+ User's Manual
1-2 Serverboard Features
At the heart of the 6027TR-HTRF+/H70RF+/H71RF+ server
lies the X9DRT-HF+, a dual processor serverboard based on the Intel
®
C602 chipset and designed to provide maximum performance. four of these
serverboards can be mounted in the SC827HQ-R1620B chassis.
The sections below cover the main features of the X9DRT-HF+ serverboard (see
Figure 1-1 for a block diagram of the chipset).
Processors
The X9DRT-HF+ supports single or dual Intel Xeon
®
E5-2600 series processors
(Socket R LGA 2011). Please refer to the serverboard description pages on our
web site for a complete listing of supported processors (www.supermicro.com).
Memory
The X9DRT-HF+ has sixteen (16) DIMM slots supporting up to 512 GB of
DDR3-1600/1333/1066/800 MHz speed registered ECC SDRAM in up to
512 MB, 1 GB, 2 GB, 4 GB, 8 GB, 16 GB or 32 GB sizes at 1.35V or 1.5V
voltages. See Chapter 5 for details.
Note: Check the Supermicro website (www.supermicro.com) for the latest memory
support information.
Serial ATA
A Serial ATA controller is integrated into each node's C602 chipset to provide up to
a six 6-port SATA subsystem. Two SATA 3 ports are available on the serverboard
(SATA 0/1) and a six port BPN-ADPX9-6SATA-O-P adapter card is mounted for
each serverboard node. RAID 0, 1, 5 and 10 are supported. The SATA drives are
hot-swappable units.
Note: The operating system you use must have RAID support to enable the hot-
swap capability and RAID function of the SATA drives.
