5-18
SUPERSERVER 6027TR-HTRF+/H70RF+/H71RF+ User's Manual
TPM Header/Port 80
A Trusted Platform Module/Port 80
header is located at JTPM1 to provide
TPM support and Port 80 connection.
Use this header to enhance system
performance and data security. See the
table on the right for pin defi nitions.
TPM/Port 80 Header (JTPM1)
Pin Defi nitions
Pin# Defi nition Pin# Defi nition
1 LCLK 2 GND
3 LFRAME# 4 <(KEY)>
5 LRESET# 6 +5V (X)
7 LAD 3 8 LAD 2
9 +3.3V 10 LAD1
11 LAD0 12 GND
13 SMB_CLK4 14 SMB_DAT4
15 +3V_DUAL 16 SERIRQ
17 GND 18 CLKRUN# (X)
19 LPCPD# 20 LDRQ# (X)
JTAG Scan (JPP0)
Jumper Settings
Jumper Setting Defi nition
Pins 1/2, 3/4 Including CPU2 in JTAG Scan
Pins 2/3
(Default)
JTAG Scan: CPU1 only
JTAG Scan (JPP1)
Jumper Settings
Jumper Setting Defi nition
Pins 1/2, 3/4 including CPU1 in JTAG Scan
Pins 2/3
(Default)
JTAG Scan: CPU2 only
IPMB I2C SMB
A System Management Bus header
for the IPMI slot is located at JIPMB1.
Connect an appropriate cable here to
use the IPMB I
2
C connection on your
system.
