Chapter 6: Advanced Chassis Setup
6-9
7. Remove the side screw from the side of the chassis (Figure 6-7).
8. Gently ease the backplane up and out of the chassis (Figure 6-8).
Figure 6-7. Loosening the Spring Bar Screws in the Floor of the Chassis
Figure 6-8. Removing the Backplane from the Chassis
1
7
1
6
1
8
